JMT ADT-K993G-BK7 PCIE 5.0 X4 / M.2 NVMe to OCuLink SFF-8611 External Dock Adapter Compatible with NUC STX ITX Motherboard Mini PC (K993G-BK7-F4Q-30cm)

JMT ADT-K993G-BK7 PCIE 5.0 X4 / M.2 NVMe to OCuLink SFF-8611 External Dock Adapter Compatible with NUC STX ITX Motherboard Mini PC This product supports not only notebooks but also NUC motherboards, STX motherboards, ITX motherboards, mini PCs, and external graphics cards. It includes adapter cards supporting M.2 NVMe interfaces and PCIe x4 interfaces. The K993G requires pairing with R29Q/F4Q to achieve full PCIe 5.0 speeds. (Motherboard interface must also support 5.0.) Product Name: OCuLink 5.0 External Graphics Card Dock Transfer Speed: PCIe 5.0 x4, Effective Bandwidth 128Gbps Product Purpose: For external graphics cards or other PCIe devices. Compared to traditional solutions, OCuLink achieves an effective bandwidth of 128Gbps under PCIe 5.0 x4 conditions, significantly surpassing Thun der solutions. Friendly Reminder: Most OCuLink devices do not support hot-swapping. Plugging and unplugging must be done with the device powered off. Power Supply Note: Supports standard ATX power supplies. Prepare the power supply according to the graphics card manufacturer's specifications. Purchasing Tip: Always purchase 1-2 samples for testing and verification before proceeding with bulk orders. Connector Specifications: Support cable to board application Small size design: pitch 0.5mm connector Supports 85 ohm impedance applications, 100 ohm is available on request Model Description: K993G-BK7-F4Q: M.2 NVMe to PCIe x16 Graphics Card Adapter with Bracket, Bandwidth PCIe 5.0 x4 K993G-BK7-R29Q: PCIe 5.0 x4 to PCIe x16 Graphics Card Adapter with Bracket, Bandwidth PCIe 5.0 x4

• The K993G Requires pairing with R29Q/F4Q to achieve full PCIe 5.0 speeds. (Motherboard interface must also support 5.0)
• K993G-BK7-F4Q: M.2 NVMe to PCIe x16 Graphics Card Adapter with Bracket, Bandwidth PCIe 5.0 x4.
• K993G-BK7-R29Q: PCIe 5.0 x4 to PCIe x16 Graphics Card Adapter with Bracket, Bandwidth PCIe 5.0 x4.
• Product Purpose: For external graphics cards or other PCIe devices. Compared to traditional solutions, OCuLink achieves an effective bandwidth of 128Gbps under PCIe 5.0 x4 conditions, significantly surpassing Thun der solutions.
• Power Supply Note: Supports standard ATX power supplies. Prepare the power supply according to the graphics card manufacturer's specifications.
• Friendly Reminder: Most OCuLink devices do not support hot-swapping. Plugging and unplugging must be done with the device powered off.
